Machining

C-Hawk specializes in temperature controlled, high-precision, contamination-free vertical milling and turning of all types of plastics, including PEEK, Ultem, UHMW, and PTFE.

Metal Machining

C-Hawk is a recognized leader in industrial craftsmanship, specializing in precision metal machining for the semiconductor industry. We have extensive expertise in working with challenging metals like Stainless Steel 316L VIM/VAR, Hastelloy®, Kovar and Inconel®. We offer a wide range of machining capabilities, from traditional methods such as turning, drilling and grinding, to advanced processes like Computer Numerical Control (CNC) machining. These techniques deliver high-precision components tailored to the unique needs of our clients.

CNC Machining

C-Hawk optimizes its metal machining capabilities with the use of advanced CNC machines for complex and precise cuts, allowing for intricate designs and tight tolerances.

Lathe

  • Hwacheon Hi-Tech 230 AL/BL Y-Axis – Max Cutting Dia Ø400mm, Max Cutting Length 560mm
  • Star Screw Machine SR-20RIV Type B – Ø20mm Max, 205mm Stroke
  • Hwacheon Hi-Tech 200A / 200B – Max Cutting Dia Ø350mm, Max Cutting Length 400mm
  • Operations: Turning, facing, grooving, threading, drilling, boring and knurling.

Mill

  • Haas 5-Axis UMC-750 – Travels: X Axis 30.0 in, Y Axis 20.0 in, Z Axis 20.0 in
  • Haas 3-Axis VF6SS – Travels: X Axis 64.0 in, Y Axis 32.0 in, Z Axis 30.0 in
  • Haas 3-Axis VF4SS – Travels: X Axis 50.0 in, Y Axis 20.0 in, Z Axis 25.0 in
  • Haas 3-Axis VF2SS – Travels: X Axis 30.0 in, Y Axis 16.0 in, Z Axis 20.0 in
  • Operations: Face milling, slot milling, end milling, thread milling, shoulder milling, side milling, profile milling and saw milling.

Grinding

Grinding involves the removal of material from a workpiece using a rotating abrasive wheel that consists of abrasive particles acting as multiple, sharp cutting tools that remove layers of material to achieve a desired form and finish.

C-Hawk Technology

At C-Hawk, we strive for the highest standards of quality. In the semiconductor and medical device sectors, where even the smallest contamination can cause significant damage to components, we take extra precautions to ensure high-purity welding. To maintain a contaminant-free environment, we operate Class 100 clean rooms equipped with Orbital and Tungsten Inert Gas (TIG) welding stations, ensuring the utmost care is taken in every aspect of our production process.

The Metal Machining Process

There are several critical steps to ensure the highest quality and precision:

  1. Material Selection: The process begins with selecting the material as required by the print for the component.
  2. Cutting and Shaping: The selected material is then cut and shaped using various machining techniques. Traditional methods like turning, drilling and grinding are employed for initial shaping, while advanced CNC machining is used for more complex and precise work.
  3. Surface Treatment: As required by the print after the initial shaping, the components undergo surface treatment processes to enhance their properties. This may include heat treatment to improve hardness and strength, as well as surface finishing techniques like polishing and coating to achieve the desired surface quality and appearance.
  4. Quality Control: Throughout the machining process, rigorous quality control measures are implemented to ensure the components meet the required specifications. This includes dimensional inspections, surface roughness measurements, and non-destructive testing methods like X-ray and ultrasonic testing.
  5. Assembly and Integration: Once the individual components are machined and inspected, they are assembled and integrated into larger systems or devices. This step may involve welding, brazing, or other joining techniques to create a complete assembly per print.
  6. Final Testing and Validation: The final step involves thorough testing and validation of the assembled components to ensure the assembly meets customer requirements.

By following this process, C-Hawk ensures that every machined component meets the highest standards of quality and precision, making them suitable for the demanding requirements of the semiconductor and medical device industries.

Curious about whether C-Hawk’s capabilities are the right fit for you?

Let’s get in touch and see how we can help you optimize your manufacturing or medical instrumentation systems from the ground up.
